Kayak HD — Installation and Service Manual
Section 3 — Configuration
Special Machine Control Options - BVW-75 Protocol
Figure 82. BVW-75 Protocol Options
Table 9. Special Machine Control Available Options
Name
Available Settings
(Default settings underlined.)
Function
Record Inhibit
“on” / “off”
Prevents deleting already recorded material. The Rec com-
mand will be switched to a Play command.
Synch.Play
“on” / “off”
Synchronized the Play command for 4 machines. This option
is needed to synchronize all 4 machines (or these machines
which have switched on this option).
NOTE: Only the Play command will be synchronized.
Synch.all Cmds
“on” / “off”
Option like Synch.Play, all Tape Motion commands will be
synchronized.
Cmd per Field
“on” / “off”
Because of the limitation of some VTRs in “on” state only one
operating command per field will be transmitted.
Timecode
“LTC“ / “CTL“
Selecting the timecode mode
