Kayak HD — Installation and Service Manual 27
System Components
1.5 and 2 M/E Control Panel
Figure 3. Kayak HD 150C, 200C, and 200 Control Panel
Figure 4. 2 M/E Control Panel, Rear View
USB P/S 2 3 4
8448_05_
r0
(Future use)
(Future use)
PS/2 Port
48V DC Power In
(from Frame)
Redundant
DC Power In
USB #4
LAN RS 485 RS 232 USB #2
