Compact Router System Configurator • User’s Guide 113
14. Glossary
3Gig The combination of SD, HD and 3.0 Gb/s video signals. Rates 270, 1,483, 1,485, 2,996, 2,970 Mb/s up
to 3.0 Gb/s.
Asynchronous In asynchronous mode, AES ‘takes’ occur in “stereo” pairs only. AES channels 1 and 2 are a pair, 3
and 4 are a pair, and so on. For example, you can take input pair (1,2) to output pair (5,6).
Breakaway A breakaway takes multiple sources on different levels to a destination.
CE Conformité Européenne. European health and safety product label.
Captive Panel The Compact Router System Configurator (CRSC) can detect, but not manage, “captive panels,”
which are unique control panels that can be mounted onto a compact router and manages only that
router in default mode.
CR Compact Router.
CQX CQX represents the “clean and quiet” compact routers and panels.
DC Direct Current.
DCHP Dynamic Host Configuration Protocol (DHCP) is an IP standard for simplifying management of
host IP configuration. Every computer on a TCP/IP network must have a unique IP address. The IP
address (together with its related subnet mask) identifies both the host computer and the subnet to
which it is attached. When you move a computer to a different subnet, the IP address must be
changed. DHCP allows you to dynamically assign an IP address to a client from a DHCP server IP
address database on your local network:
EIA Electronic Industries Alliance. A trade organization for electronics manufacturers in the United
States. The organization helps develop standards on electronic components, consumer electronics,
electronic information, telecommunications, and Internet security.
HD High Definition (HD-SDI). Video signal rates: SMPTE 259M at 1.483 and 1.485 Gb/s .
IEC International Electrotechnical Commission. An international standards organization dealing with
electrical, electronic and related technologies.
IEEE Institute of Electrical & Electronics Engineers. An international non-profit, professional organiza-
tion for the advancement of technology related to electricity.
I/O Input/Output.
LAN Local Area Network.
Remote Panel
(RP) A remote panel is a control panel that is mounted on a remote panel module. In addition to remote
panels, the Compact Router System Configurator (CRSC) can manage to a limited degree “captive
panels,” which are unique control panels that can be mounted onto a compact router converting the
compact router into a control panel.
Remote Panel
Module A remote panel module enables a user to connect to a system controller via a network to control a
connected compact router. A control panel may be attached to a remote panel module to create a
remote panel, which is configurable using the Compact Router System Configurator (CRSC).
RU Rack Unit. A standard measure or size for frames (1.75 inches).
