48 Rev 2.0 • 29 Mar 10
7. Programming Remote Panels
Overview
How to Change the Panel Operation Mode
1 From the left-hand navigation area, expand the ‘System Configuration’ pane and click ‘Pro-
gram Remote Panels’.
2 Click the ‘Remote Panels’ tab at the bottom of the page to bring it forward and then click the
‘Edit/Update’ radio button in the row listing the panel you want to update. The remote panel’s
configuration displays in the page.
3 In the ‘Remote Panel’ section at the top of the page, click on the button you want to update.
4 In the ‘Panel Mode’ field, from the drop-down list select a mode of operation: ‘Standard’,
‘Enhanced — Hold’, or ‘Enhanced — No Hold’. For a description of each mode, see Remote
Panel Modes on page 38.
5 When you have finished defining button functions, click
Update Panel
to write the button con-
figuration to the remote panel.
6 Important! Click
Save to File
to save the configuration in your PC’s file system. The extension
for panel configuration files is .pfg.
Important CQX panels have a default configuration and are not configurable at this time.
