54 Rev 2.0 • 29 Mar 10
9. Firmware Updates
Discussion
The columns present the following options and information:
How to Update Firmware
1 Select individual compact routers or remote panels by checking the check box in ‘Select’ col-
umn on the row listing the device.
Or
Click
Select All
to select all devices.
To deselect all devices and start again, click Select None . To execute a firmware update, you
must have selected at least one device in the device list.
2 (Optional) Clear the ‘Only update if versions are different’ check box if you want to force every
selected device to be updated. Otherwise, a device is updated only when the firmware is differ-
ent from the firmware in the device. CRSC automatically checks the firmware version.
3 Click
Update Firmware
. The ‘Select the Compact Router Firmware’ dialog box appears.
Figure 9-2. Select the Compact Router Firmware Dialog Box
Column Description
Select Check the check box to select the device listed on that row for updating.
Name Name of the compact router or remote panel.
Frame Type Type of compact router or remote panel, such as CP3232
IP Address IP address currently assigned to the device.
Boot (uC) Version Boot code for initial boot up.
Application (uC) Version Application code that exists on the router.
Firmware (FPGA) Version Hardware application downloaded to the router.
