Compact Router System Configurator • User’s Guide 57
10. Lock Maintenance
The ‘Lock Maintenance’ page enables you to view all locks, clear individual locks or clear all
locks. Using this page, locks can be cleared that cannot be cleared at the control panel. If the page is
empty, there are no destination locks set. Locks are available on all control panels, including the
CQX panel.
There are two types of locks:
• Panel Lock — Locks the entire panel preventing accidental changes.
• Destination Lock — A locked destination is one to which a source may not be routed. This pre-
vents the content delivered at the destination from being changed. When the lock is released,
the destination’s content can be changed.
the ‘Lock Maintenance’ page manages only destination locks. Panel locks are managed at the
individual panel.
To open the ‘Lock Maintenance’ page, from the ‘Administrative Tools’ pane, click ‘Lock Main-
tenance’. At any time, click
Refresh Summary to refresh the list.
Discussion
Using the ‘Lock Maintenance’ Page
Locks are listed for each output that is locked, not for each level nor for each destination. A single
destination lock usually includes locks on several levels.
Figure 10-1. Lock Maintenance Page
