14
Tables, Overviews and Diagrams
TNC 124
117
Technical information
TNC data
Brief description
Contouring control with analog speed control
for machines with up to 4 axes (axis control
for up to 3 axes, position display for a fourth
axis)
Programming
HEIDENHAIN conversational programming
Program memory
20 part programs
capacity
2 000 program blocks
1 000 program blocks in each program
Position data
Single-axis Cartesian coordinates;
absolute or incremental
Unit of measurement
Millimeters or inches
Display step
Depending on encoders and machine
parameters,
e.g. 0.005 mm for graduation period of 20 µm
Input range
0.001 mm (0.000 5 in.) to 99 999.999 mm
(3 937 in.); 0.001° to 99 999.999°
Max. range of traverse
+/ 10 000 mm
Maximum feed rate
30 000 mm/min
Maximum spindle speed
99 999 rpm
Number of tools
in the tool table
99
Datum points
99
Data interface
RS-232-C/V.24
Data transfer rate
110, 150, 300, 600, 1 200 baud
2 400, 4 800, 9 600, 38 400 baud
Programming
program section repeats
Subprograms; Program section repeats
Fixed cycles
Pecking;
Tapping with a floating tap holder
Circular hole pattern; Linear hole pattern;
Rectangular pocket milling
Ambient temperature
Operation: 0° C to 45° C
Storage: 30° C to 70° C
Weight
Approx. 6.5 kg
Power consumption
Approx. 27 W
