HEIDENHAIN NC 124 User Manual
Page 121
Sequence of Program Steps
Milling an outside contour
Operating mode:
PROGRAMMING AND EDITING
Program step
1
Open or select program
Entries:
Program number
Unit of measurement in the program
2
Calling tool data
Entries:
Tool number
Spindle axis
Separately:
Spindle speed
3
Tool change
Entries:
Coordinates of the tool change position
Radius compensation
Separately:
Feed rate (rapid traverse) and
Miscellaneous function (tool change)
4
Approach starting position
Entries:
Coordinates of the starting position
Radius compensation (R0)
Separately:
Feed rate (rapid traverse) and
Miscellaneous function (spindle ON, clockwise)
5
Move to (first) working depth
Entries:
Coordinates of the (first) working depth
Feed rate (rapid traverse)
6
Move to first contour point
Entries:
Coordinates of the first contour point
Radius compensation for machining
Separately:
Machining feed rate
7
Machining to last contour point
Entries:
Enter all required data for all
contour elements
8
Move to end position
Entries:
Coordinates of the end position
Radius compensation (R0)
Separately:
Miscellaneous function (spindle STOP)
9
Retract tool
Entries:
Coordinates above the workpiece
Separately:
Feed rate (rapid traverse) and
Miscellaneous function (end of program)
10
End of program
