16:9 Aspect Ratio Image or Screen
Screen or image size Projection distance (1)
Offset from top of
projector (2)
Offset from top of
projector (3)
100 inches (254 cm)
3.9 inches (9.8 cm)
5.9 inches (14.9 cm)
54.9 inches (139.4 cm)
110 inches (279.4 cm) 5.3 inches (13.5 cm)
6.7 inches (16.9 cm)
60.6 inches (153.9 cm)
120 inches (304.8 cm) 6.8 inches (17.3 cm)
7.5 inches (19 cm)
66.3 inches (168.4 cm)
130 inches (330.2 cm) 8.3 inches (21 cm)
8.3 inches (21 cm)
72 inches (182.9 cm)
150 inches (381 cm)
11.2 inches (28.5 cm)
9.9 inches (25.1 cm)
83.4 inches (211.9 cm)
4:3 Aspect Ratio Image or Screen
Screen or image size Projection distance (1)
Offset from top of
projector (2)
Offset from top of
projector (3)
66 inches (167.6 cm)
1 inch (2.6 cm)
4.3 inches (11 cm)
43.9 inches (111.6 cm)
70 inches (177.8 cm)
1.7 inches (4.4 cm)
4.7 inches (12 cm)
46.7 inches (118.7 cm)
80 inches (203.2 cm)
3.5 inches (9 cm)
5.7 inches (14.5 cm)
53.7 inches (136.4 cm)
90 inches (228.6 cm)
5.4 inches (13.6 cm)
6.7 inches (17 cm)
60.7 inches (154.1 cm)
100 inches (254 cm)
7.1 inches (18.1 cm)
7.7 inches (19.5 cm)
67.7 inches (171.9 cm)
110 inches (279.4 cm) 8.9 inches (22.7 cm)
8.7 inches (22 cm)
74.7 inches (189.6 cm)
120 inches (304.8 cm) 10.8 inches (27.3 cm)
9.7 inches (24.5 cm)
81.6 inches (207.3 cm)
122 inches (309.9 cm) 11.1 inches (28.2 cm)
9.8 inches (25 cm)
83 inches (210.9 cm)
16:10 Aspect Ratio Image or Screen
Screen or image size Projection distance (1)
Offset from top of
projector (2)
Offset from top of
projector (3)
74 inches (188 cm)
0.9 inches (2.3 cm)
4.3 inches (10.8 cm)
43.5 inches (110.4 cm)
80 inches (203.2 cm)
1.9 inches (4.7 cm)
4.8 inches (12.1 cm)
47.2 inches (119.8 cm)
90 inches (228.6 cm)
3.5 inches (8.8 cm)
5.6 inches (14.3 cm)
53.4 inches (135.5 cm)
100 inches (254 cm)
5 inches (12.8 cm)
6.5 inches (16.5 cm)
59.5 inches (151.2 cm)
110 inches (279.4 cm) 6.7 inches (16.9 cm)
7.4 inches (18.8 cm)
65.7 inches (166.8 cm)
