30
16:10 Aspect Ratio Image or Screen
Screen or image size Projection distance (1)
Offset from top of
projector (2)
Offset from top of
projector (3)
120 inches (304.8 cm) 8.2 inches (20.9 cm)
8.3 inches (21 cm)
71.9 inches (182.5 cm)
130 inches (330.2 cm) 9.8 inches (24.9 cm)
9.1 inches (23.2 cm)
78 inches (198.2 cm)
138 inches (350.5 cm) 11.1 inches (28.2 cm)
9.8 inches (24.9 cm)
83 inches (210.7 cm)
Parent topic:
Related tasks
Changing the Projected Image Using Flexible Picture
Projector Connections
See these sections to connect the projector to a variety of projection sources.
Caution:
If you will use the projector at altitudes above 4921 feet (1500 m), turn on
High Altitude Mode
to ensure the projector's internal temperature is regulated properly. See the menu link below.
Caution:
Check the shape and orientation of the connectors on any cable you plan to connect. Do not
force a connector into a port if it does not fit. The device or your projector could be damaged or could
malfunction.
Caution:
Depending on the connected device and the shape of the cable, you may not be able to attach
the projector's side cover. Do not force the cover into place or the device or the projector could be
damaged or could malfunction.
Connecting to an HDMI Video Source
Connecting to a USB Device
Connecting a Streaming Device
Connecting a Gaming Device
Connecting External Speakers Using HDMI ARC
Connecting to External Speakers
Connecting to a Bluetooth Audio Device
Connecting Headphones
