Uniview IPC675LFW-AX4DUPKC-VG 5MP Outdoor Mini PTZ Active Deterrence Network Camera with Night Vision - Manual (Page 11)

6
Live View Toolbar
Item Description
Set the image display ratio in the window.

Scale: Displays 16:9 images.

Stretch: Displays images according to the window size (stretch images
to fit the window).

Original: Displays images with original size.
Set the image display mode in the window.

Single Channel: Displays live video of a single channel.

Left/Right Split: Displays live video in left/right split mode.

Top/Bottom Split: Displays live video in top/bottom split mode.

Picture in Picture: Opens a floating live view window on top of the current
window.
NOTE!
This function is only available on dual-channel cameras.
: Stop/start live view of the selected channel.
: Start local recording.
: Switch streams.
Select a live video stream according to your camera.
Set image parameters.
/
Start/stop live view.
/
Turn off/on sound.
Adjust the output volume for the media player on the PC.
Range: 1 to 100.
Adjust the microphone volume on the PC during audio communication
between the PC and the camera.
Range: 1 to 100.
Frame rate/bit rate/resolution/packet loss rate.
Take a snapshot from the displayed live video.
NOTE!
See Local Parameters for the path of the saved snapshots.
/
Start/stop local recording.
NOTE!

See Local Parameters for the path of the saved local recordings.

VLC media player is recommended for playing local recordings of 4K
cameras.
/
Start/stop two-way audio.
/
Start/stop digital zoom. See Digital Zoom for details.
/
Start/stop capturing. See Snapshot for details.
Full screen.
Show/hide PTZ control panel.
1
2 3
1
2
3
