26
You can use the defaults or customize them in case of port conflicts.
CAUTION!
•
If the HTTP port number you entered has been used, a message “Port conflicts. Please try again.”
will appear. 23, 81, 82, 85, 3260, and 49152 have been assigned for other purposes and cannot be
used.
•
In addition to the above port numbers, the system can also dynamically detect other port numbers
that are already in use.
HTTP/HTTPS Port: If you change the HTTP/HTTPS port number, then you need to add the new port
number after the IP address when logging in. For example, if the HTTP port number is set to 88, you
need to us
to log in to the camera.
RTSP Port: Real-Time Streaming Protocol port, enter an available port number.
Click
Save
.
2.
Port Mapping
Configure port mapping so computers on the WAN can access your camera on the LAN.
Go to
Setup
>
Network
>
Port
>
Port Mapping
.
Enable
Port Mapping
.
Select the mapping type.
UPnP
Auto: Enable UPnP on the router, then the external port numbers are assigned automatically.
Manual: The external port numbers need to be set manually.
Manual
If your router does not support UPnP, you need to set the external port numbers manually.
