87

Adjust the position and size of the tripwire.
Point to the tripwire and drag it to the desired position. Drag the endpoints of the tripwire to resize it.

Draw a tripwire.
Click in the preview window to draw a tripwire.
Set the people flow counting rule.
Item Description
Data Report
Interval(s)
Set the time interval for the camera to report people flow statistics.
Default: 60.
Range: 1 to 60.
For example, if the interval is set to 60, the camera will report people flow statistics to the server
every 60 seconds.
Reset Counter at

Select the Reset Counter at check box and set a time for the camera to clear people
counting statistics on the OSD.

To clear now, click Clear .
Enter Set the entry direction.
Counting Type
Select the counting type.
Before use, configure a people counting OSD first. See
OSD for details.

Total: The number of people entering and leaving the area is displayed in real time on the
video image.

People Entered: The number of people entering the area is displayed in real time on the
video image.

People Exited: The number of people leaving the area is displayed in real time on the video
image.
People Present
Alarm
Set the people present alarm threshold. When the number of people present reaches a set
threshold, an alarm is triggered.
Range: 1 to 180.

Minor Alarm: A minor alarm is triggered when the number of people present reaches the
set value.

Major Alarm: A major alarm is triggered when the number of people present reaches the
set value. The value of major alarm must be greater than that of minor alarm.

Critical Alarm: A critical alarm is triggered when the number of people present reaches the
set value. The value of critical alarm must be greater than that of major alarm.
Set the alarm-triggered actions and arming schedule. See Alarm-triggered Actions and Arming
Schedule for details.
