91
Max. Size/Min.
Size
When enabled, a box appears on the image, you can point to a handle of the box and drag to
resize it. The camera filters objects larger than the Max. Size or smaller than the Min. Size. The
width and height of the maximum filter area must be greater than that of the minimum filter area.
Tracking Click to set tracking parameters. See Tracking for details.
Set the alarm-triggered actions and arming schedule. See Alarm-triggered Actions and Arming
Schedule for details.
Click Save .
5.6.18 Smoke and Fire Detection
Smoke and fire detection detects smoke and fire in the visible light channel and triggers an alarm. The
camera uploads the original snapshots triggered by smoke and fire alarms by default.
Go to Setup > Intelligent > Smart .
Select Smoke and Fire Detection and click to configure it.
Set the detection rule.

Bounding Box Overlay: A rectangular box is used to frame the object that triggers the detection rule
for you to quickly locate it.

Sensitivity: Set the detection sensitivity. The higher the sensitivity, the more likely smoke and fire will
be detected, and the more likely false alarms will occur.

Shield Area: Shield areas that may interfere with detection or trigger false alarms. A total of 64
shielding areas are allowed, with a maximum of 8 shielding areas per image.
(1) Move the camera to the desired position manually or using presets.
