Uniview IPC675LFW-AX4DUPKC-VG 5MP Outdoor Mini PTZ Active Deterrence Network Camera with Night Vision - Manual (Page 78)

73
Filter Type
After you select a detection object, you can set a filter rule for it.
For example, if you have selected
Motor Vehicle as a detection object, select Motor Vehicle
from the Filter Type drop-down list and set the Max. Size or Min. Size for it, then motor
vehicles larger than the Max. Size or smaller than the Min. Size will not be detected.
Max. Size/Min.
Size
When enabled, a box appears on the image, you can point to a handle of the box and drag
to resize it. The camera filters objects larger than the Max. Size or smaller than the Min. Size.
The width and height of the maximum filter area must be greater than that of the minimum
filter area.
Set the alarm-triggered actions and arming schedule. See Alarm-triggered Actions and Arming
Schedule for details.
Click Save .
5.6.6 Intrusion Detection
Intrusion detection detects objects entering a user-specified area and staying for a preset time. The
camera reports an alarm when the detection rule is triggered.
Go to Setup > Intelligent > Smart .
Select Intrusion and click to configure it.
Add a detection rule.
(1) Click to add a detection area. The detection area is a hexagon by default. Up to 4 detection
rules are allowed.
