Uniview IPC675LFW-AX4DUPKC-VG 5MP Outdoor Mini PTZ Active Deterrence Network Camera with Night Vision - Manual (Page 132)

127
Item Item Description
Control
Mode
Serial Port
The wiper is controlled through PELCO-D instructions, so the PTZ protocol
must be set to PELCO-D. See PTZ Protocol for more information.
Alarm Input/Output
Use alarm input and output to open or close the circuit and control the
wiper.
Enable
Wiper
Normally
Open/Normally Closed Set according to the actual working status of the wiper.
Move Mode
One
Time/Repeat/Automatic
One Time: The wiper works once every time you click the wiper icon on the
PTZ control panel.
Repeat: You need to set the Effective For and Time Interval parameters.
The Effective For parameter sets the duration of the Repeat mode (1 to 24
hours), and the Time Interval parameter sets the interval between two
wiper movements (1 to 60 minutes).
NOTE!
If Time Interval is set to 60 minutes and Effective For is set to 1 hour, then
the wiper works once at the last minute and then stops.
Only integers are allowed.
Automatic: Use a rain sensor to detect rains and automatically activate the
wiper when the threshold is reached.
(3) Click Save .
5.10.6 Maintenance
1. Maintenance
System maintenance include software upgrade, system configuration, diagnosis information, power
output, and heater settings.
Go to
Setup > System > Maintenance .

Software upgrade
NOTE!
• Make sure the version to be used matches the device; otherwise, exceptions may occur.
• The version file is a .zip file that includes all the upgrade files.
• Power must be connected throughout the upgrade.
 Local upgrade
(1) Click Browse , locate the version. (If applicable) select Upgrade Boot Program to upgrade the
boot program.
(2) Click Upgrade to start. The device will restart automatically after the upgrade is completed.
 Peripheral upgrade
Check for upgradable peripherals such as pan/tilt unit, illuminator, etc., and available versions.
 Cloud upgrade
Click Detect to check for new versions. You can perform a cloud upgrade if a new version is
available on the cloud server.

System configuration
You can export the current configurations of the camera to the client computer or an external storage
device for backup, so when necessary, you can restore camera configurations by importing the backup
file.
