123
Item Description
Server IP Server’s IP address.
Server Port Use the default port.
VIID Version Choose the correct version, VIID_2017 or VIID_2018.
Device ID
Make sure the entered device ID conforms to the VIID protocol, and digits 11-13 must be
119.
Username
Username configured at VIID Management > VIID Device Management > Gateway
Authentication on the VM.
Platform Access Code Password configured at
VIID Management > VIID Device Management > Gateway
Authentication on the VM.
Confirm Platform
Access Code
Enter the password again.
Configure the VIID parameters.
Item Description
Coordinate Mode Includes Percentage Mode , Pixel Mode , and Normalized Mode .
Connection Mode
Short Connection: This mode is implemented based on the standard HTTP protocol, and
the server decides the connection mode.
Standard: This mode is applicable only when the camera connects to a Uniview server.
Report Data Type Types of date to be reported.

LAPI
Only Intelligent Server 2 supports LAPI. Choose LAPI and then click Save .
5.10.4 Device Information
Set device information including device name, location, mounting height, etc., which can be used in smart
FTP, OSD, etc.
Go to Setup > System > Device Info .
Complete the information as needed.
Click
Save .
5.10.5 Ports & External Devices
The RS485 port is used for data transmission between the camera and external third-party devices for
PTZ control, OSD, audio collection, illumination control, etc. The serial port parameters configured on
the camera must match that of the connected external device.
