63
5.5.3 Privacy Mask
Privacy mask is used to cover certain areas on the image for privacy, for example, ATM keyboard.
NOTE!
• This function may vary with device model.
• For dual-channel devices, you can set privacy mask parameters for the channels separately.
Go to Setup > Image > Privacy Mask .
Select the mask mode, Rectangle or Polygon .

2D-mask camera: For a PTZ camera, the privacy mask does not move and zoom with the camera.

3D-mask camera: For a PTZ camera, the privacy mask moves and zooms with the camera and the
masked area is always covered.
Add a privacy mask.
(1) Click Add . The privacy mask is a rectangle by default.
(2) Adjust the position and size of the mask or draw a mask as needed.
 Adjust the position and size of the mask.
̶ Point to a border of the mask and drag it to the desired position.
̶ Point to a handle of the mask and drag to resize it.
 Draw a mask.
̶ Polygon: Click on the image and drag to draw a line. Repeat the action to draw more lines to
form an enclosed shape as needed. Up to 4 lines are allowed.
̶ Rectangle: Click on the image and drag to draw a rectangle.
Set the privacy mask.
