5 leave area detection, Leave area – Uniview IPC675LFW-AX4DUPKC-VG 5MP Outdoor Mini PTZ Active Deterrence Network Camera with Night Vision User Manual
Page 76
71
(2) Adjust the position and size of the area or draw an area as needed.
Adjust the position and size of the area.
̶
Point to a border of the area and drag it to the desired position.
̶
Point to a handle of the area and drag to resize it.
Draw an area.
Click on the image and drag to draw a line. Repeat the action to draw more lines to form an
enclosed shape as needed. Up to 6 lines are allowed.
Set the detection rule.
Item
Description
Sensitivity
Set the detection sensitivity.
The higher the sensitivity, the more likely entry behaviors will be detected, and the more likely
false alarms will occur.
Level
Select the priority of the detection rule, including
High
,
Medium
, and
Low
.
The camera detects the rule that is triggered first by default. If multiple rules are triggered at
the same time, the camera detects the rule with higher priority.
Detection Object
Select the object to be detected, including
Motor Vehicle
,
Non-Motor Vehicle
, and
Pedestrian
.
Filter Type
After you select a detection object, you can set a filter rule for it.
For example, if you have selected
Motor Vehicle
as a detection object, select
Motor Vehicle
from the
Filter Type
drop-down list and set the
Max. Size
or
Min. Size
for it, then motor
vehicles larger than the Max. Size or smaller than the Min. Size will not be detected.
Max. Size/Min. Size
When enabled, a box appears on the image, you can point to a handle of the box and drag
to resize it. The camera filters objects larger than the Max. Size or smaller than the Min. Size.
The width and height of the maximum filter area must be greater than that of the minimum
filter area.
Set the alarm-triggered actions and arming schedule. See
Click
Save
.
5.6.5
Leave Area Detection
Leave area detection detects objects leaving a user-specified area. The camera reports an alarm when
the detection rule is triggered.
Go to
Setup
>
Intelligent
>
Smart
.
