Uniview IPC675LFW-AX4DUPKC-VG 5MP Outdoor Mini PTZ Active Deterrence Network Camera with Night Vision - Manual (Page 84)

79
Item Description
Snapshot Area
Select the snapshot area.

Full Screen: The camera detects and captures all faces in the live video.

Specified Area: The camera only detects and captures faces in a specified area of live
video.
 Select Specified Area and a detection box appears in the left preview window.
 Adjust the position and size of the area or draw an area as needed.
̶ Adjust the position and size of the area. Point to a border of the area and drag it to the
desired position. Point to a handle of the area and drag to resize it.
̶ Draw an area. Click on the image and drag to draw a line. Repeat the action to draw
more lines to form an enclosed shape as needed. Up to 6 lines are allowed.
Snapshot Sensitivity
Set the snapshot sensitivity.
The higher the sensitivity, the more likely a face will be detected.
Snapshot Mode
Set the snapshot mode.

Intelligent Recognition: The camera continuously performs face detection.

Alarm Input: The camera only performs face detection in the event of an alarm input. Before
use, you need to enable alarm input and configure arming schedule for it. See Alarm Input
for details.
Human Body
Snapshot
Select to enable or disable human body snapshot.
Min. Pupillary
Distance (px)
The minimum distance (measured in pixels) between two pupils. The face with pupillary
distance smaller than the value will not be captured.
To set the minimum pupillary distance, you can click
Draw and drag the corners of the box in
the preview window to resize it, or type the pupillary distance value in the text box.
Static Object
Detection
Select whether to detect static objects.
Counting
After you enable Counting and select the people counting direction, the statistics of people
entering or leaving are displayed on the live image.
Before use, please configure a people counting OSD overlay on the
OSD page. See OSD for
details.
Reset Counter at

Select the Reset Counter at check box and set a time for the camera to clear people
counting statistics.

To clear people counting statistics immediately, click Clear Counting Result . This
operation only clears the people statistics displayed on the OSD, and does not affect the
reported data.
Set the face selection rule.
Item Description
Selection Mode
Select the face selection mode.

Effect Priority: The camera selects 1 to 3 snapshots with the best quality to report. You can
specify the number of photos to select.

Speed Priority: The camera selects certain number of snapshots from the moment that the
face is detected till Selection Timeout is up. You can specify the number of photos to
select.

Periodic Selection: The camera selects a snapshot in every selection period. For example,
if Selection Period is set to 500ms, the camera selects a face snapshot every 500ms, and
if Upload Original Image is enabled, both the original snapshot containing the face and
the face cutout will be uploaded.
