15
Item Description
Speed
Set how fast the camera rotate. 1 means the slowest, 9 means the fastest.
Tilt Gradient
The average division value of the vertical distance between the start and end presets.
The greater the value, the shorter the patrol route.
Initial Patrol Direction
The direction of the first rotation from the start preset to the end preset.
Start/End Preset
Select a preset from the drop-down list as the start/end preset. The start and end
presets must be different.

Record a patrol route
On the PTZ control panel, click Patrol .
Click to start recording. You can adjust the direction, rotation speed and zoom of the camera
during recording. All movement data of the camera will be recorded.
Click to finish recording and the recording is saved as a patrol route automatically.
A Start preset
B End preset
A1
B1
Tilt gradi
Initial patrol direction: anti-clockwise
Camera
A Start preset
B End preset
A1
B1
Initial patrol direction: clockwise
Tilt gradient
Camera
