35
5.3.1 Video
1. Video
Go to Setup > Video & Audio > Video .
Select a capture mode for your camera.
The Extended Encoding function is available only when the capture mode is greater than 8MP.
After you change the capture mode, the encoding settings will be reset to defaults and some models of
cameras will restart.
Set stream parameters.
The streams are independent of each other and can be set with different resolutions, frame rates, video
compression formats, etc. Only the main stream supports full resolution.
NOTE!
• The fourth and fifth streams are only available on certain models.
• Before configuring the fifth stream, you need to enable the fourth stream first.
Item Description
Video
Compression
Select a video compression standard for your camera: H.265 , H.264 or MJPEG .
NOTE!
• When H.265 or H.264 is selected, Image Quality is not available; When MJPEG is selected,
Bit Rate , I Frame Interval , Smoothing , SVC and U-Code are not available.
• The bit rate restores to the default when you switch between H.264 and H.265.
Resolution Select a video resolution for your camera. The higher the resolution, the clearer the image.
Frame
Rate(fps)
Select the frame rate.
NOTE!
To ensure image quality, the frame rate shall not be greater than the reciprocal of the shutter
speed.
Bit Rate(Kbps)
Set the bit rate. Range: 128 to 16384.
NOTE!
The bit rate range may vary with device model.
