19
SETUP
"BASIC SETTINGS"
3 TRACTOR
- Upon first switching on, Bravo 400S starts the guided setup procedure for the
Tractor
: go through each step selecting the desired options (example in Fig. 39).
- When the message in Fig. 40 appears, the tractor configuration is complete. Press
OK
.
- Press
ESC
and return to the
Settings menu
.
Fig. 38
OK
Next step
ESC
Previous step
Fig. 39
Fig. 40
BASIC TRACTOR SETTINGS
• A100
: ARAG receiver code 520100.693.
• Smart-Ag / Smart 6:
ARAG receivers code 467016xx.
• NMEA
: all GPS receivers with NMEA183 protocol and with the following features:
- 10 Hz GGA message; latitude and longitude coordinates with at least 6 decimal digits.
- 10 Hz VTG message.
- 0.1 Hz. ZDA message.
- Serial port 57600 bps, n, 8, 1.
• Demo
: Bravo 400S simulates the driving.
• None
4 Basic setup procedure is now complete (*). Now it is possible to start the advanced setup procedure, described in ch. 10.
(*) This can be started again at any time, by selecting
Start
in the
Implement
and
Tractor
menu.
END 9 Basic settings
Par.
Exits the function
or data change
Confirm access
or data change
Scroll
(LEFT /
RIGHT)
Delete
selected
character
Increase /
Decrease
of data
Scroll
(UP /
DOWN)
Enter
selected
character
