ADVANCED SETUP "GENERAL OPTIONS"
10.3.4 Steering warning
Fig. 184
Allows to enable/disable the acoustic alarm when the operator must steer in order to align the machine with
the following track, avoiding unsprayed or overlapping areas between the two sprays
(
Steering radius set in par. 10.1.11 Working parameters).
Signal enabled
Signal disabled
GUIDANCE
10.3.5 Offset tolerance
Fig. 185 Fig. 186
The guidance screen displays a LED bar
according to the offset with respect to the
reference line.
Each LED indicates an offset value
corresponding to the one set in item
Offset
tolerance (for ex.: 30 cm).
PREFERENCES
10.3.6 Selective job loading
Fig. 187
Fig. 188
Allows to enable/disable the screen Loading options
(Fig. 188) when the operator loads a previously saved
job (par. 13.5
F5 Resume job).
Screen enabled
Screen disabled
Par.
7.4
Exits the function
or data change Confirm access
or data change
Scroll
(LEFT /
RIGHT) Delete
selected
character Increase /
Decrease
of data Scroll
(UP /
DOWN) Enter
selected
character
