"JOB MENU" - F7 ZOOM ALL
POINTS OF INTEREST MARKING
2
1
2
2
2
A
Fig. 304
The generic points of interest can be memorized with this procedure
or with the relevant function (par. 15.3.2). More points can be marked.
In this screen it is possible to memorize a field point even if the tractor is in a
different position:
1 In the field overview (Fig. 304) press the
OK
key.
Cursor
A
will appear.
2 Press
F4
/
F6
/
F7
/
F8
to shift the cursor on the exact point to be
marked.
3 Press
OK
4 Press
F7
/
F8
to select the type of marker.
5 Press
OK
to confirm (Fig. 306).
4
3
4
Fig. 305
5
Fig. 306
POINTS OF INTEREST REMOVAL
1 In the field overview (Fig. 307) press the
OK
key. Cursor
A
. will appear.
2 Press
F4
/
F6
/
F7
/
F8
to shift the cursor near or on the marked point;
when the point is selected, the symbol
will appear in the middle of the cursor.
3 Press
OK
twice to delete (Fig. 308) /
ESC
to cancel.
2
1
2
2
2
A
Fig. 307
3
4
Fig. 308
Par.
Exits the function
or data change
Confirm access
or data change
Scroll
(LEFT /
RIGHT)
Delete
selected
character
Increase /
Decrease
of data
Scroll
(UP /
DOWN)
Enter
selected
character
