Gardtec 600 PCB Fitting Instructions
Fitting the 600 PCB (plastic case)
Make sure all mains power is disconnected before fitting the PCB.
After fitting the case to the wall, and feeding the cables through the relevant entries,
mount the 600 PCB as shown in the figure 1:-
1. Make sure that the inner retaining clips are in place and the PCB sits squarely
on the support pillars. (See figure 1). Make sure the PCB is secure.
Note the orientation of the PCB, the terminal strip is facing the mains trans
former.
2. Connect the two orange transformer wires to the two terminals marked A.C.
on the PCB. (See figure 1).
3. Connect the two battery wires to the battery terminal on the PCB. Note the
polarity. Black -, Red +. (See figure 1).
Fitting the 601 PCB (metal case)
When fitting the 601 PCB to the metal case follow the B26 Enclosure Assembly
Guide then follow the additional steps outlined below.
1. Leave the tamper spring in place.
2. Connect the Tamper Cable to the right angled pin header next to the tamper
switch. (JP2 on the PCB). (See figure1). Note the orientation, the
connector will only fit one way round.
