22) Press No. The display will show:-
23) Press Yes. The display will show:-
Note: Zone Response time is defaulted to 400ms and may not
be changed.
24) Press Yes. The display will show:-
Note: Fault /Mask response time may be programmed as a
global parameter and may be reprogrammed from 2 to 14
seconds. (increments of 2 seconds).
The time programmed for this option will apply to all zones, there is no option for individual response
times per zone. It is a global setting.
Once the Fault / Mask as been triggered the response time for the Fault / Mask will revert to the
default time of 400ms until the fault / mask problem has cleared.
25) Press No until the settings you require are
displayed. Then press Yes. The display will show:-
Wiring Modes available are:-
8 (2 Wire) Two wires are used for the zone and a global tamper is used.
(Depending on Version / Grade - Cannot be used in Grade 3
installations).
(EOL) Two wires are used in conjunction with two resistors to give
End Of Line wiring, this is the most secure wiring format.
For information on how to wire the various wiring modes, please refer to the
back of this manual, or refer to the Quick Start Guide that is supplied with the
control panel.
If selecting 8(EOL) follow steps 26 - 28. If selecting 8(2 Wire) jump to step 29.
26) With the display showing:-
Press Yes.
27) The display will show:-
Page 15
GT 600 / 601 Engineer’s Reference Guide
Program Zone
Wiring ?
On-Board Zones
=8 <EOL>
Zone Response
:400 mS
Fault / Mask Zones
Response=Norm
On-Board Zones
=8 <EOL>
On-Board EOL
=Norm
