Rugged Cams HD Megapixel - Manual (Page 109)

109
Number Description
1 DVR name
2 Start and finish recorded date and time
3 The version of the firmware
4 The number of Connected network(ex. CMS, Mobile CMS, etc.) to the DVR
11.3.3.3
PTZ Control
 Under the server list, PTZ control can be found. This is for the control of Pan/Tilt/Zoom.
 Buttons on the screen have the following functions.
- Up/Down/Left/Right direction buttons
- Zoom In/Out, Focus Near/Far, Iris Close/Open
- Preset Control button
 Please choose the number from the drop down list from 1 to 256.
 After selecting the number, please type the description on the empty space below the drop down list and click “Save”.
 If users think that the certain spot is important or need to have precautions, then they can set up the spot as ‘Preset’.
 When the preset is setup up, click ‘Go Preset’ to move to preset spot.
- PTZ control menu can be hidden by clicking PTZ ICON below the PTZ menu.
11.3.3.4
System Log
 In the Live mode, system Log is shown. This will allow users to check System Log of Remote Site (DVR).
Zoom Out/ In
Focus Near / Far
Iris Close / Open
