126
1
Fast Forward/Backward & Playback
(Click the button to increase the speed by x1,
x2, x4, x8, x16, x32, x64 and Extreme)
2 Sequence Mode
3
Display Mode( Click the button to divide the
screen by 1, 4, 9, 16 and Full
4 Time Bar (24 Hour)
5 Data Bar (Recorded data)
6 Time Select Bar
 When Date/Time search is completed, please click ‘Play
’ button to begin playback.
12.4.2 Event Search
 The Event search allows users to search event recorded data of DVR.
 To start the event search, please click ‘EVENT’ and users will see the following screen.
 Please choose one of the devices among the ‘Server List’ and right click on the mouse to have popup menu with Connect.
 Please click ‘Connect’ to start the event search
 Event search has three different parts called Event Type, Select Camera and Date/Time setting.
① Event Type: it has three event types which are Emergency, Alarm and Motion. Please choose one event that users want
to detect.
② Select Camera: Please select the camera that users want to view from Cam1 to Cam 16 for the event (Only 1 camera
can be selected).
③ Date/Time setting: Please select the begin and end time by clicking the up/down arrows and click “Search”
12.4.3 POS/ATM
 POS/ATM button allows users to search for the POS/ATM text.
①
⑤
④
② ③
⑥
