Mechanical installation
Motor mounting
4
l
97 EDK82MV371 DE/EN/FR 7.0
Motor mounting
Scope of supply
8200mot049
4 ×
1b
1a
M4 × 25
2
3
1a Carrier housing
1b Electronic module
2 Distance and wall plate
3 Self−tapping screw for the wall mounting
