Tennis Operations 133
Section 11: Tennis Operations
Sport Insert: LL-2483
The Sport and Team Name Insert drawings are located in Appendix B. The System Riser drawing is
located in Appendix A.
Reference Drawings:
Insert; LL-2441 A/S 5000, Team Name .............................................................. Drawing A-125290
Insert; LL-2483 A/S 5000, Tennis ....................................................................... Drawing A-131274
System Riser; Tennis; Single Court w/ TNMC, AS 5000 .................................... Drawing A-177098
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
Use the label sheet provided with the console (Daktronics part # LL-2458) to attach the correct code
number label to the sport insert in the designated location. Write the code number in the space below.
If viewing a digital copy of this manual, print this page and fill in the code number.
Write the correct code number here:
If the code number for a scoreboard is unknown, refer to Appendix C. If the model number of a
scoreboard is unknown, refer to the documentation provided with the scoreboard.
11.1 Tennis Keys
Serve
Display Action
Press <SERVE> to turn the serve indicators on or off for the
respective side.
Press the same <SERVE> key again or the opposite side
<SERVE> key to disable the serve indicator.
Doubles Serve
Display Action
Press <DOUBLES SERVE> to turn the serve indicators on or
off for the second player for the respective side.
Press the same <DOUBLES SERVE> key again to disable
the second player serve indicator.
TOP SERVE
ON
TOP SERVE
2ND ON
