Pitch & Speed Operations 45
Section 5: Pitch & Speed Operations
Sport Insert: LL-2482 Code: 5500
The Sport Insert drawing is located in Appendix B. The Quick Reference is located in Appendix D.
Reference Drawings:
Insert; LL-2441 A/S 5000, Team Name .............................................................. Drawing A-125290
Insert; LL-2482 A/S 5000, Pitch and Speed ........................................................ Drawing A-130895
Speed Adjust Calculations, Radar Gun ............................................................... Drawing A-243741
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
5.1 General Pitch & Speed Information
The pitch and speed program interfaces with a JUGS ® or STALKER ® radar gun to provide
pitch and speed information. The pitch type and speed can be displayed on a matrix display,
while only the speed may be displayed on a fixed digit display.
For more information about radar gun setup, refer to the Radar Gun Speed of Pitch Systems
Configuration Manual (ED-12224), available online at
www.daktronics.com/manuals .
5.2 Pitch & Speed Keys
Pitch Keys
Note: In Auto mode, the pitch keys are not used.
The keys on the left side of the keypad are used to select the type of pitch for manual display
mode. In manual display mode, the console waits to send the received pitch speed until a
pitch type key is pressed. Once a pitch type is selected, the pitch data is updated on the
display and sent as Real-Time Data (RTD).
Display Speed
<DISPLAY SPEED> is used in manual mode to send the speed to the display as speed only
(blank frame).
Blank Time
Display Action
MM:SS = minutes, seconds
Press <BLANK TIME > to set length of time before speed
and pitch data is blanked on the display. If this value is set at
00:00, the speed and pitch data will be displayed
continuously.
BLANK TI ME
MM:SS*
