Australian Rules Football/Cricket Operations 273
Section 24: Australian Rules Football/Cricket
Operations
Sport Insert: 0G-315384 Australian Rules Football Code: 6699
Cricket Code: 5699
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A.
Reference Drawings:
Block Diagrams, A/S 3000 or 5000 Outdoor Sports............................................ Drawing A-124690
Insert; LL-2442 A/S 5000, Team Name .............................................................. Drawing A-125290
Insert; Cricket/Football ........................................................................................ Drawing A-315384
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
Write the code number in the space below. If viewing a digital copy of this manual, print this page
and fill in the code number.
Write the correct code number here:
24.1 Australian Rules Football Keys
Red On/Off, Green On/Off
The <RED ON/OFF> and <GREEN ON/OFF> keys set the substitution status.
Display Action
Press <RED ON/OFF> once to turn on the red indicator;
press it again to turn off the red indicator.
Press <GREEN ON/OFF> once to turn on the green indicator;
press it again to turn off the green indicator.
RED I NDI CATOR
ON
RED I NDI CATOR
OFF
GREEN I NDI CATOR
ON
GREEN I NDI CATOR
OFF
