Daktronics All Sport 5000 Series Operation Manual - Manual (Page 208)

190 Event Counter
Value/Days
Display Action
NNN = current value
Press the <VALUE/DAYS •> key.
Enter the number of days for countdown (0 – 999) using the
number pad.
Use the <SET MAIN CLOCK> key to set the time to be counted.
Press <START> to start the main clock. If the console is set to count down, the time and day
values decrements until 0 days, 00:00:00.0 time. The console then begins counting up and
counts the days and time that have elapsed since the event occurred. If the console is set to
count up, the timer begins at 0 days, 00:00:00.0 time and continues until <STOP> is pressed.
Note: If the console is set to stop at zero, the clock will not begin counting up until the
<START> key is pressed again.
15.3 Time Based Counting Codes
Display Action
NNNNNNN = current value
HH:MM:SS = hours, minutes,
seconds
The current value is shown on the top line of the LCD. The
time remaining until the next increment (or decrement) is
shown on the bottom line.
Value/Days
Display Action
NNNNNNN = current value
Press <VALUE/DAYS •> to begin counting from the entered
initial value. The value can be up to eight digits.
DAYS
NNN*
VALUE = NNNNNNNN
NXT I NC HH:MM:SS
VALUE
NNNNNNNN*
