Basketball Operations 79
Setting Result
N = current setting
In count down mode, the switch closes when the main clock
reaches zero and remains closed until a nonzero value is
entered.
In count up mode, the switch closes when the main clock
reaches the proper period, break, or overtime length and
opens when any other value is entered.
N = current setting
The switch closes when the main clock is stopped and opens
when the main clock is running. External devices are disabled
when the main clock is running.
N = current setting
The switch closes when the main horn sounds. This could be
when Auto Horn is enabled and the main clock reaches zero
or when <HORN> is pressed.
Default Settings
Print this page if necessary, and record any custom settings for this installation:
Setting Default Custom 1 Custom 2 Custom 3
Number of Periods 4
Tenth of a Second Yes
Period Length 8:00
Break Length 10:00
Overtime Length 5:00
Shot Clock Tenth Sec. No
Shot Clock Reset 1 0:45
Shot Clock Reset 2 0:30
Sync Shot with Main Yes
Shot Clock Auto Blank Yes
Full Time Outs 3
Full Time Out 1:00
Time Out Warning 0:00
Partial Time Outs 2
Partial Time Out 00:20
Partial Time Out Warn 0:00
Show on Main No
Update Player Score No
Update Player Fouls Yes
1-on-1 Bonus 7
2-Shot Bonus 10
Select Captions 1-ON
Show Fouls on Stats No
Score by Quarter No
Switch Output 1-Clock = 0
SWI TCH OUTPUT=N
1-CLOCK =0?
SWI TCH OUTPUT=N
2-CLOCK =STOP?
SWI TCH OUTPUT=N
3-MAI N HORN?
