Rugby Operations 259
Section 23: Rugby Operations
Sport Insert: 0G-712154 Rugby Code: 6690 (Union) or 6691 (League)
The Sport and Team Name Insert drawings are located in Appendix B. The Block Diagram drawings
are located in Appendix A.
Reference Drawings:
Block Diagrams, A/S 3000 or 5000 Outdoor Sports............................................ Drawing A-124690
Insert; LL-2442 A/S 5000, Team Name .............................................................. Drawing A-125290
Insert; Rugby ....................................................................................................... Drawing A-712154
Refer to the information in Section 2 to start up the console and use the sport insert.
If an insert is lost or damaged, a copy of the insert drawing can be used until a replacement arrives.
Write the code number in the space below. If viewing a digital copy of this manual, print this page
and fill in the code number.
Write the correct code number here:
23.1 Rugby Keys
Time Out On/Off
<TIME OUT ON/OFF> stops and starts the time out clock. The length of both the full and
partial time outs can also be changed when the time out clock is stopped.
Note: Only the time outs configured in the EDIT SETTINGS function are displayed on
the LCD and available for selection.
Display Action
MM:SS = minutes, seconds
Press <TIME OUT ON/OFF> to display the configured time
for full time out length.
To start the full time out press <YES>.
To decline the selection of the full time out press <NO>.
TI ME OUTS-SELECT
FULL MM:SS
