222 Judo Operations
The possible settings for the switch output are as follows:
Setting Result
N = current setting
The switch remains open at all times and any external devices
are disabled.
N = current setting
In count down mode, the switch closes when the main clock
reaches zero and remains closed until a nonzero value is
entered.
In count up mode, the switch closes when the main clock
reaches the proper period, break, or overtime length and
opens when any other value is entered.
N = current setting
The switch closes when the main clock is stopped and opens
when the main clock is running. External devices are disabled
when the main clock is running.
N = current setting
The switch closes when the main horn sounds. This could be
when Auto Horn is enabled and the main clock reaches zero
or when <HORN> is pressed.
Default Settings
Print this page if necessary, and record any custom settings for this installation:
Setting Default Custom 1 Custom 2 Custom 3
Main Clock Period Length 4:00
Wazaari Time 20
Ippon Time 25
Medical Time 0:60
Switch Output 1-Clock = 0
SWI TCH OUTPUT=N
0-DI SABLED?
SWI TCH OUTPUT=N
1-CLOCK =0?
SWI TCH OUTPUT=N
2-CLOCK =STOP?
SWI TCH OUTPUT=N
3-MAI N HORN?
