Section 7 COPIER MANAGEMENT FUNCTIONS
7-23
● Paper size (drawer[cassette] No.2 & No.3)
Perform the following procedure to set the size of paper that is loaded
in drawer[cassette] No.2 and No.3.
1 Display the “Machine default” screen.
(See “(2) Accessing the machine default settings” on
page 7-21.)
Inch specifications
Default setting
Default setting
Copy
default Weekly
timer
Machine
default
Language Management
End
BOX
Management Bypass
setting
Document
Management Print
report
Metric specifications
Default setting
Default setting
Copy
default
Machine
default
Language
Bypass
setting
Management Week
timer
End
Hard Disk
Management
Document
Management Print
report
2 Select one of the “Paper size” settings
(“2nd drawer[cassette]” or “3rd drawer[cassette]”) in the
settings list on the left side of the touch panel and then
touch the “Change #” key.
The screen to set the paper size for that drawer[cassette] will
be displayed.
Inch specifications
Default setting
Machine default
Auto drawer switching
Paper size(2nd drawer)
Paper size(3rd drawer)
Paper type(1st drawer)
Paper type(2nd drawer)
On / All types of paper
Auto / Inch
Auto / Inch
Plain
Plain
Default menu
Down
Change #
Close
Setting mode
Up
Default setting
Metric specifications
Default setting
Machine default
Auto cassette switching
Paper size (2nd cassette)
Paper size (3rd cassette)
Paper type (1st cassette)
Paper type (2nd cassette)
On / All types of paper
A4
A4
Plain
Plain
Up
Down
Change #
Close
Default setting
Default menu Setting mode
3 Perform the step that corresponds to the specification of your
copier:
<Inch specification copiers>
If you select “Auto Detecton” (automatic size detection) here,
select the desired unit of measure (“Centimeter” or “Inch”) as
well.
If you select “Standard sizes” (standard paper size) here,
simply touch the key that corresponds to the size of paper
that is loaded in that drawer[cassette].
Paper type(2nd drawer)
Select paper size.
Default setting - Machine default
A3 B4
B5
B5
11x17"
8 1 / 2 x14"
5 1 / 2 x8 1 / 2 "
8 1 / 2 x13"
11x8 1 / 2 "
8 1 / 2 x11"
A4
A5 Folio
A4
Auto
Detection
Standard
sizes
Back Close
<Metric specification copiers>
Select the size of paper that is loaded in that
drawer[cassette].
Paper size (2nd cassette)
Select paper size.
Default setting - Machine default
A3 B4
B5
B5
11x17"
8 1 / 2 x14"
5 1 / 2 x8 1 / 2 "
8 1 / 2 x13"
11x8 1 / 2 "
8 1 / 2 x11"
A4
A5 Folio
A4 Auto
Standard sizes
Back Close
NOTE
If you want to quit the displayed setting without changing it, touch the
“Back” key. The touch panel will return to the screen in step 2.
4 Touch the “Close” key. The touch panel will return to the
screen in step 2.
5 Touch the “Close” key once again. The touch panel will return
to the “Default setting” screen.
6 Touch the “End” key. The touch panel will return to the
contents of the “Basic” tab.
