Section 10 MAINTENANCE AND OPERATION INFORMATION
10-2
2. Specifications
Type ............................................................................... Console
Original table .................................................................. Main Body: Fixed type
When using the Document Processor: Moving type
Copying system ............................................................. Indirect electrostatic system
Acceptable originals ....................................................... Sheets of paper, books and 3-dimensional objects (Maximum size: 11" x 17" / A3)
Copy sizes ..................................................................... Drawers[Cassettes]: 11" x 17" / A3, 8
1/2
" x 14" / B4 (257 mm x 364 mm), 11" x 8
1/2
" / A4,
8
1/2
" x 11" / A4R, 5
1/2
" x 8
1/2
" / A5R, and Folio (metric specification copiers) ,
B5, and B5R (Asia Pacific specification copiers)
Multi-bypass tray: 11" x 17" / A3, 8
1/2
" x 14" / B4 (257 mm x 364 mm), 11" x 8
1/2
" / A4,
8
1/2
" x 11" / A4R, 5
1/2
" x 8
1/2
" / A5R, A6R and Folio (metric specification copiers) ,
B5, B5R, and B6R (Asia Pacific specification copiers)
For 2-sided copying: 11" x 17" / A3 – 5
1/2
" x 8
1/2
" / A5R
Print margin loss: 0.5 mm – 5.5 mm
Copying speed ............................................................... 63 cpm copiers, same size (100%; [1:1]), memory copy
11" x 17" / A3: 32 copies/min., 8
1/2
" x 14" / B4: 38 copies/min.,
11" x 8
1/2
" / A4: 63 copies/min., 8
1/2
" x 11" / A4R: 44 copies/min. ,
B5: 63 copies/min., B5R: 50 copies/min.
75 cpm copiers, same size (100%; [1:1]), memory copy
11" x 17" / A3: 38 copies/min., 8
1/2
" x 14" / B4: 45 copies/min.,
11" x 8
1/2
" / A4: 75 copies/min., 8
1/2
" x 11" / A4R: 52 copies/min. ,
B5: 75 copies/min., B5R: 60 copies/min.
Warm-up time ................................................................. Within 360 secs. (at room temperature of 68
F/20C, humidity 65%) Recovery from the
preheat mode: Within 30 seconds
First copy speed ............................................................. 63 cpm copiers: Approx. 3.6 secs. (11" x 8
1/2
" / A4 horizontal feed from drawer[cassette] No.1)
75 cpm copiers: Approx. 3.2 secs. (11" x 8
1/2
" / A4 horizontal feed from drawer[cassette] No.1)
Available magnification ratios ......................................... Any 1% increment between 25% and 400% or standard pre-set ratios
* Between 25% and 200% when using the Document Processor
Standard Memory .......................................................... 128 MB
Image Storage Memory ................................................. 20 GB
Resolution ...................................................................... Reading: 600 x 600 dpi
Writing: 1800 equivalent x 600 dpi
Paper feed system ......................................................... Automatic feeding from drawers[cassettes] (two 500-sheet capacity drawers[cassettes]
[80 g/m
2
] and one 3000-sheet capacity drawer[cassette] [80 g/m
2
]), or from the multi-bypass
tray (100 sheet capacity [80 g/m
2
])
Acceptable copy paper .................................................. <Paper weights>
Drawers[Cassettes]: 60 g/m
2
– 80 g/m
2
Duplex Unit: 64 g/m
2
– 105 g/m
2
Multi-bypass tray: 45 g/m
2
– 200 g/m
2
; 110 lbs.
<Paper types>
Drawers[Cassettes]: Standard copy paper and color paper
Duplex Unit: Standard copy paper and color paper
Multi-bypass tray: Standard copy paper, letterhead, color paper, tracing paper,
OHP transparencies, envelopes, etc. (envelopes can only be used under the optional printer
functions of this machine.)
Continuous copying ....................................................... 1 – 999 sheets
Light source ................................................................... Rare gas lamp
Developing system ......................................................... Dry process
Fixing system ................................................................. Heat roller
Cleaning system ............................................................ Blade and fur brush
Photoconductor .............................................................. a-Si
Standard functions and modes ...................................... Auto paper selection mode, Image quality selection, Auto magnification selection mode,
Zoom mode, Preset zoom mode, XY zoom mode, 2-sided copy modes, Page separation/
Split copy modes, Margin mode, Centering/Image shift mode, Memo mode, Border erase
modes, Combine/Merge Copy modes, Print page numbers mode, Form overlay mode,
Booklet/Stitching mode, Book to Booklet mode, Sort/Finished mode, Auto rotation function,
Auto Selection/Filing mode, Cover mode, Transparency + backing sheet mode, Invert mode,
Mirror image mode, Proof mode, Repeat copy mode, Batch scanning mode, Eco print
mode, Program function, Job build mode, Form registration, Shared data box, Synergy print
boxes, Copy management mode, Weekly timer function, Language selection function
