Section 8 OPTIONAL EQUIPMENT
8-3
3 Copying in the Sort-Staple mode
1 Touch the “Function” tab and then touch the “Sort/Finished”
key. The “Sort/Finished” screen will be displayed.
Inch specifications
2 sided/
Separation Select
paper
Combine
Reduce
/Enlarge
Margin/
Centering Forms
Overlay Page #
Function Basic User choice Program
Cover
Mode
Booklet Sort/
Finished Border
Erase
Exposure
mode
Orig.image
quality
Ready to copy.
Select
orig. size
Auto
Selection Batch
scanning
Up
Down
Set Paper size
11x8 1 / 2 "
Metric specifications
Select
paper 2-sided/
Split
Merge copy
Reduce/
Enlarge
Margin/
Imag. shift Page
numbering
Function Basic User choice Program
Cover
Mode Booklet Erase
Mode
Exposure
mode
quality
Sort/
Finished
Ready to copy.
Select
size orig.
Auto
selection Large # of
originals
Form
overlay
Up
Down
Set Paper size
2 Touch the “Staple mode” key.
The “Staple mode” screen will be displayed.
Inch specifications
Sort:OFF Off
On Sort:ON
O f f s e t S o r t S t a p l e
Staple
mode
P u n c h
Punch
mode
Back Register Close Sort/Finished
Ready to copy.
Rear
Left top
corner
Check direction
Check direction of
original top side.
Set Paper size
11x8 1 / 2 "
Metric specifications
Sort:Off None
Output
each page
Sort:On
G r o u p S o r t S t a p l e
Staple
Mode
P u n c h
Punch
Mode
Back Register Close Sort/Finished
Ready to copy.
Back Edge
Left top
corner
Check direction
Check direction of
original.
Set Paper size
3 Touch the key that corresponds to the desired number of
staples.
Inch specifications
Back Close Staple mode
Ready to copy.
None
1 staple
Rear
Left top
corner
Check direction Staple
Set Paper size
2 staples
Check direction of
original top side.
11x8 1 / 2 "
Limited number of staple pages.
The limit is set in setting mode.
When selecting staple function
the offset can not be combined.
Metric specifications
Back Close Staple Mode
Ready to copy.
None
1 staple
Back Edge
Left top
corner
Check direction Staple
Check direction of
original.
Set Paper size
2 staples
Limited number of pages to be stapled.
The limitation depends on setting mode.
Cannot combine sort function and
staple.
* The stapling position will be displayed on the image of the
finished copies that appears in the touch panel, as shown
in the illustration below. Verify the number and position of
the staples before copying. When the combination of the
selected functions does not allow stapling, the staple marks
will appear on the displayed image.
Orientation of
originals
No and
position
of staples
1 staple
Top left
stapling
1 staple
Top right
stapling
2 staples
Left side
stapling
2 staples
Right side
stapling
2 staples
Top stapling
Stapling
Not possible
