Section 9 TROUBLESHOOTING
9-19
5 5 5 5 5 Misfeed in the Document Processor
If the message below is displayed, a misfeed has occurred in the
Document Processor. Perform the following procedure to remove the
jammed paper.
Inch specification
Paper misfeed.
1.Open cover of Document processor.
2.Lift reversing unit up.
3.Turn the left dial.
4.Remove original.
5.Close cover of Document processor.
JAM 00
Metric specification
Paper misfeed.
1.Open cover of Document processor.
2.Lift reversing unit up.
3.Turn the left knob.
4.Remove original.
5.Close cover of Document processor.
JAM 00
1 Remove all of the originals remaining in the original table.
2 Open the Document Processor cover.
3 If there is an original there, remove the jammed original
without tearing it.
* If the original does happen to tear, remove any loose
scraps from inside the Document Processor. Loose scraps
of paper may cause other originals to misfeed.
4 Lift open the reversing unit.
5 If there is an original there, remove the jammed original
without tearing it.
* If the original does happen to tear, remove any loose
scraps from inside the Document Processor. Loose scraps
of paper may cause other originals to misfeed.
* If the original is difficult to remove, turn the original feed dial
as shown in the illustration in order to feed it out to a
location that makes it easier to remove.
6 Close the reversing unit in its original position.
7 Close the Document Processor cover.
