Section 9 TROUBLESHOOTING
9-13
3 Turn the green conveyor knob in the direction of the arrow
shown in the illustration. The paper will be transported to the
paper conveyor unit.
4 Pull the paper conveyor unit out slowly.
5 Remove the jammed paper without tearing it.
* If the paper does happen to tear, remove any loose scraps
from inside the copier.
2 2 2 2 2 Misfeed in the paper conveyor section
If a misfeed occurs in the paper conveyor section, perform the
following procedure to remove the jammed paper.
* When a misfeed has occurred in the paper conveyor section,
the following message will appear after you open the front cover in
step 1.
Inch specification
Paper misfeed.
1.Turn green lever counterclockwise.
2.Turn right green knob clockwise.
3.Pull out transfer unit.
JAM 00
Metric specification
Paper misfeed.
1.Turn green lever to the left.
2.Turn right green knob clockwise.
3.Pull out transfer unit.
JAM 00
1 Open the front cover.
2 Push the green release lever down to the left.
WARNING
High voltage is present in the charger section. Take
sufficient care when working in this area, as there is
a danger of electrical shock.
