5-2
Operation on the Machine > Loading Originals
Loading Originals
Placing Originals on the Platen
You may place books or magazines on the platen in addition to ordinary sheet originals.
When you place envelopes or cardstock on the platen
NOTE
For details on Original Orientation, refer to Original Orientation on page 6-10 .
NOTE
For the procedure for feeding envelopes or cardstock, refer to When you load envelopes or cardstock in the multi
purpose tray on page 3-20 .
CAUTION
Do not leave the document processor open as there is a danger of personal injury.
IMPORTANT
• Do not push the document processor forcefully when you close it. Excessive pressure may crack the platen
glass.
• When placing books or magazines on the machine, do so with the document processor in the open
position.
Align it flush against
the original size
indicator plates with
the back left corner
as the reference
point.
Put the scanning
side facedown.
Put the scanning
side facedown.
Align it flush against
the original size
indicator plates with
the back left corner
as the reference
point.
