6-9
Using Various Functions > Functions
Paper Selection
Select the cassette or multi-purpose tray that contains the required paper size.
Select from [1] (Cassette 1) to [5] (Cassette 5) to use the paper contained in that cassette.
If [Auto] is selected, the paper matching the size of the original is selected automatically.
To select [MP tray], press [Paper Size] and [Media Type], and specify the paper size and the media type. The available
paper sizes and media types are shown in the table below.
NOTE
• Specify in advance the size and type of the paper loaded in the cassette (refer to Cassette/MP Tray Settings on
page 8-9 ).
• Cassettes 2 to 5 are displayed when the optional paper feeder is installed.
Item Value Description
Paper Size Metric A4-R, A5-R, A6-R, B5-R, B6-R, Folio,
216 × 340 mm Select from the Metric standard sizes.
Inch Letter-R, Legal, Statement-R, Executive, Oficio II Select from the Inch series standard sizes.
Others 16K-R, ISO B5, Envelope #10, Envelope #9,
Envelope #6, Envelope Monarch, Envelope DL,
Envelope C5, Hagaki, Oufuku Hagaki, Youkei 4,
Youkei 2, Custom
*1
*1 For instructions on how to specify the custom paper size, refer to Custom Paper Size on page 8-13 .
Select from special standard sizes and custom
sizes.
Size Entry Metric
X: 70 to 216 mm (in 1 mm increments)
Y: 148 to 356 mm (in 1 mm increments) Enter the size not included in the standard size. *2
When you have selected [Size Entry], use [+]/[-]
or the numeric keys to set the sizes of "X"
(horizontal) and "Y" (vertical).
*2 The input units can be changed in System Menu. For details, refer to Measurement on page 8-17 .
Inch
X: 2.76 to 8.50" (in 0.01" increments)
Y: 5.83 to 14.02" (in 0.01" increments)
Media type Plain (60 to 105 g/m 2 ) Transparency, Rough, Vellum (60 to 63 g/m 2 ), Labels, Recycled, Preprinted *3 ,
Bond, Cardstock, Color, Prepunched *3 , Letterhead *3 , Envelope, Thick (106 to 220 g/m 2 ), High Quality,
Custom 1-8 *3
*3 For instructions on how to specify the custom paper types 1 to 8, refer to Media Type Setting on page 8-14 . To print on preprinted
or prepunched paper or on letterhead, refer to Special Paper Action on page 8-14 .
NOTE
• You can conveniently select in advance the size and type of paper that will be used often and set them as default
(refer to Multi Purpose Tray on page 8-10 ).
• If the specified size of paper is not loaded in the paper source cassette or multi purpose tray, a confirmation screen
appears.
