8-14
Setup and Registration (System Menu) > System Menu
Media Type Setting
The following media type and paper weight combinations are available.
Media Type Setting Select weight for each media type.
For Custom 1-8, settings for duplex printing and media type name can be changed.
For details, refer to
Media Type Setting on page 8-14 .
Default Paper Source Select the default paper source from Cassette 1-3 and multi purpose tray.
Value : Cassette 1 to 5, Multi Purpose Tray
NOTE
[Cassette 2] to [Cassette 5] are displayed when optional paper feeder is installed.
Paper Selection Set the default paper selection.
Value
Auto: Automatically select the cassette containing paper in the same size as originals.
Default Paper Source: Select paper source set by
Default Paper Source .
Media for Auto (B&W) Select a default media type for auto paper selection when [Auto] is selected of Paper Selection.
If Plain is selected, the paper source with plain paper loaded in the specific size is selected.
Select [All Media Types] for the paper source with any kind of paper loaded in the specific size.
Value : All Media Types, Plain, Transparency, Rough, Vellum, Labels, Recycled,
Preprinted, Bond, Cardstock, Color, Prepunched, Letterhead, Envelope, Thick,
High Quality, Custom 1 to 8
Special Paper Action When printing on Prepunched, Preprint, and Letterhead, punch-holes might not be aligned or
the print direction might be upside-down depending on how originals are set and the
combination of copying functions. In such a case, select [Adjust Print Direction] to adjust the
print direction. When paper orientation is not important, select [Speed Priority].
Example: copying on Letterhead
Value : Adjust Print Direction, Speed Priority
Common Settings Paper Settings Media Type Setting
Paper Weight Weight (g/m
2
) Paper Weight Weight (g/m
2
)
Light 60 g/m² to 63 g/m² Heavy 1 106 g/m² to 135 g/m²
Normal 1 64 g/m² to 74 g/m² Heavy 2 136 g/m² to 170 g/m²
Normal 2 75 g/m² to 90 g/m² Heavy 3 171 g/m² to 220 g/m²
Normal 3 91 g/m² to 105 g/m² Extra Heavy Transparencies
Item Description
Multi Purpose Tray Cassette Finished Paper Original
Multi Purpose Tray Cassette Finished Paper Original
