IEC-101 Slave ♦ ProLinx Communication Gateway
IEC 60870-5-101 Slave Interoperability Statement
IEC 60870-5-101 v3 Slave (Firmware version 3.xx)
Protocol Manual
ProSoft Technology, Inc.
Page 139 of 159
August 6, 2010
6.8.8 Command Transmission
(Object-specific parameter; mark "
X" if function is only used in the standard
direction, "
R" if only used in the reverse direction, and "B" if used in both
directions)
Direct command transmission
Direct set point command transmission
Select and execute command
Select and execute set point command
C_SE_ACTTERM used
note 2
No additional definition
Short pulse duration (duration determined by a system parameter in the
outstation)
Long pulse duration (duration determined by a system parameter in the
outstation)
Persistent output
Supervision of maximum delay in command direction of commands and
set point commands
60 seconds Maximum allowable delay of commands and set point commands
6.8.9 Transmission of Integrated Totals
(Station- or object-specific parameter; mark "
X" if function is only used in the
standard direction, "
R" if only used in the reverse direction, and "B" if used in
both directions)
Mode A: Local freeze with spontaneous transmission
Mode B: Local freeze with counter interrogation
Mode C: Freeze and transmit by counter-interrogation commands
Mode D: Freeze by counter-interrogation command, frozen values
reported spontaneously
Counter read
Counter freeze without reset
Counter freeze with reset
Counter reset
General request counter
Request counter group 1
Request counter group 2
Request counter group 3
Request counter group 4
