Phantom Power
Supplies +48 VDC to XLR Inputs including Talkback.
1. Reset – Returns all settings to factory default
(all phantom power off).
2. Input Channel buttons – Touch
to enable or disable phantom power for the
channel.
3. Rear Panel View XLRs – Touch
to enable or disable phantom power for the
channel.
OIUT!: Phantom power may also be
controlled from the Setup screen of each
input channel.
OIUT!: It is good practice to turn off
phantom power when connecting or
disconnecting an input. “Hot patching” a
device can cause severe transients and
potentially damaging current surges.
Press
Mic 48V
