Scenes
Scenes provide the ability to store and recall all mix
parameters.
1. Current Scene – Displays the name of the
most recently recalled scene.
2. Save / Save As button – Displays
a page with options for naming a scene and
selecting internal or USB storage.
3. Factory scenes list – A library of
preset scenes representing mixer settings for a
variety of bands, productions and styles. Factory
memory is read-only.
4. Mixer scenes list – Displays a list of
scenes that have been saved to the mixer’s
internal memory.
5. USB list – Displays a list of scenes that
have been saved to an attached USB memory.
device.
6. Copy to USB – Copies the selected scene
from Internal memory to an attached USB
memory device.
7. Copy to Mixer – Copies the selected
scene from an attached USB memory device to
Internal memory.
8. Delete – Deletes the selected Internal or
External scene.
9. Recall – Recalls the selected Scene.
10. Recall Options – Scenes are saved with all parameters but it isn’t always desireable to recall all parameters. This section can be
set so that some mixer settings are not effected by a scene recall.
a. Omit Levels – Mix levels including Aux sends, FX sends and Output levels are uneffected.
b. Omit Outputs – Output EQ, Anti-Feedback, Comp/Limiter are uneffected.
c. Omit Routing – Sub Group and Main L/R assignments are uneffected.
TIMIOUCOUN!: It is possible to recall TouchMix-8 and TouchMix-16 scenes on a TouchMix-30 Pro. Of course the
TouchMix-30 Pro has far more inputs and outputs. These excess inputs and outputs will be set to factory default values.
Touch
Scenes
OR Touch Menu
Touch
Scenes
Default
Scene:
OR Menu Scenes
2
4 5
1
8
9
7
10
6
10c
3
10a 10b
8
