1001108-01-F

Mute Groups

There are many times when it is useful to mute some of the inputs and outputs. For example, you might want to mute everything but a stereo input
for break music. Or there may be a part of your show when the band leaves the stage while one member does a solo number. Mute groups let you
mute multiple inputs and outputs from a single button. For more information on mutes, see

"Mutes" on page 19

To set up Mute Groups:

Mute

Groups

Edit

Mute 1

In 1

Select channels to be assigned

To name the Mute Group:

Mute Joe

New Verb

Mute Group Name

Select another Mute group to set up or touch

Close Edit

Close Edit to finish.

To use Mute Groups:

Mute

Groups

Mute

NOTE:

Mute Groups can be assigned to the User Buttons.

"User Buttons" on page 24

NOTE:

When a channel is muted by a Mute Group, the channel Mute button on the Home screen looks like:

Mute

DCA Groups

A DCA groups faders together so the overall level of all the channels in the group can be controlled by a single DCA fader.
A DCA fader does not change the position of any of the faders in the group.

IMPORTANT:

Here is an important thing to know – if the DCA master fader is at 0.0 (the unity (U) mark), it does nothing to the

level of an assigned channel. The DCA adds or subtracts level. Move the DCA Fader up 3 dB and everything it’s assigned to will
increase by 3 dB. Move it down 3 dB and – well you probably figured that out. Remember that assigning or unassigning a channel
to a DCA Group can cause a sudden change in the level of the channel so it’s good practice to have the DCA master at 0.0 when
changing assignments.

To Setup a DCA Group:

DCA Groups

DCA 1

In 1

In 3

Continue selecting channels as you

wish.

You can assign inputs, outputs and FX Master faders to a DCA. If you assign an input, and the output to which it's going to the same DCA, changes
you make using the DCA are doubled for the input. Raise the DCA 3 dB, the input is effectively raised 6 dB.

To Name the DCA group:

Drums

DCA Name

To Mute a DCA Group:

DCA Groups

Mute

When you mute a DCA, all channels assigned to that DCA are muted. If a channel is muted by the channel Mute button, or a Mute Group, the DCA
does not un-mute the channel when the DCA is un-muted.
