QSC Audio TouchMix-30 Pro 32-Channel Compact Digital Mixer with Touchscreen - Manual (Page 86)

77
1001108-01-F
FX Masters − Presets
Recall presets for the selected FX channel based on the
current FX device.
1. Presets tab – Selects the Presets screen.
2. Current Preset – Displays the name of
the currently active preset (if any).
3. Save / Save As button – Displays
a page with options for naming a scene and
selecting internal or USB storage destination.
4. Factory list – Displays a list of the factory
programmed presets available for the currently
loaded FX device. Touch a preset name to select.
5. Mixer (internal) list – Displays a list
of presets that have been stored to Internal
mixer memory.
6. USB (external) list – Displays a list of
presets that have been saved on an External
(USB) drive.
7. Delete button – Deletes a selected preset
from Internal or External user memory.
8. Copy to USB button – Copies the
selected preset to an external USB Drive.
9. Copy to Mixer button – Copies the
selected preset to the internal mixer memory.
10. Recall button – Recalls the effects
parameters of a preset selected in the Factory,
Mixer or USB list. Recall does not affect Aux Sends, EQ, Mutes, or Group assignments.
Press Home
Touch
FX Masters
Select an
FX Channel
Touch
Presets
Inputs 1-8
FX 1
FX Masters
Presets
